SMT PCB sib dhos yog dab tsi?

SMT PCB sib dhos yog ib txoj hauv kev uas cov khoom siv hluav taws xob tau txuas ncaj qha mus rau saum npoo ntawm lub rooj tsav xwm luam tawm.Nws tso cai rau cov khoom sib txuas ncaj qha rau ntawm qhov chaw mount PCB.Cov cuab yeej no yuav pab kom cov khoom me me.

Surface mount technology yog qhov ua tau siv ntau tshaj plaws.Yog li ntawd, nws daim ntawv thov yog dav heev.Raws li nto mount thev naus laus zis encapsulates ntau thiab ntau cov khoom siv hluav taws xob hauv qhov chaw me me, cov cuab yeej siv niaj hnub no feem ntau siv thev naus laus zis nto.Yog li thaum miniaturization ua ntau dua thiab tseem ceeb, qhov tseem ceeb ntawm SMT thev naus laus zis yog qhov tseeb ntawm tus kheej.

PCBFuture muaj ntau tshaj 10 xyoo ntawm kev paub hauv SMT PCB los ua ke.Los ntawm cov txheej txheem kev sib dhos SMT automated, peb lub rooj tsav xwm Circuit Court tuaj yeem ua kom muaj kev ua tau zoo tshaj plaws hauv cov ntawv thov nyuaj.

Dab tsi yog SMT PCB sib dhos

Dab tsi yog cov txheej txheem rau SMT PCB los ua ke?

Cov txheej txheem ntawm kev siv SMT los tsim cov khoom siv PCB suav nrog kev siv cov tshuab tsis siv neeg los sib sau cov khoom siv hluav taws xob.Lub tshuab no tso cov ntsiab lus ntawm lub rooj tsav xwm hauv Circuit Court, tab sis ua ntej ntawd, cov ntaub ntawv PCB yuav tsum tau kuaj xyuas kom paub meej tias lawv tsis muaj teeb meem cuam tshuam rau kev tsim khoom thiab kev ua haujlwm ntawm lub cuab yeej.Tom qab lees paub tias txhua yam zoo tag nrho, cov txheej txheem ntawm SMT PCB sib dhos tsis txwv rau kev sib dhos thiab tso cov khoom lossis cov khoom sib txuas ntawm PCB.Cov txheej txheem tsim khoom hauv qab no kuj yuav tsum tau ua raws.

1. Siv cov tshuaj txhuam hniav

Thawj kauj ruam thaum sib sau ua ke SMT PCB pawg thawj coj saib yog siv cov tshuaj txhuam hniav.Cov tshuaj nplaum tuaj yeem siv rau PCB los ntawm kev siv tshuab silk screen.Nws tseem tuaj yeem siv tau siv PCB stencil tailored los ntawm cov ntaub ntawv CAD zoo sib xws.Koj tsuas yog yuav tsum tau txiav cov stencils siv lub laser thiab siv cov tshuaj txhuam hniav rau qhov chaw uas koj yuav solder cov khoom.Daim ntawv thov solder paste yuav tsum tau nqa tawm hauv qhov chaw txias.Thaum koj ua tiav daim ntawv thov, koj tuaj yeem tos qee lub sijhawm rau kev sib dhos.

2. Kev tshuaj xyuas koj cov tshuaj txhuam hniav

Tom qab cov tshuaj txhuam tau siv rau lub rooj tsavxwm, cov kauj ruam tom ntej yog yuav tsum tau kuaj xyuas nws los ntawm cov txheej txheem tshuaj xyuas cov txheej txheem.Cov txheej txheem no yog qhov tseem ceeb, tshwj xeeb tshaj yog thaum txheeb xyuas qhov chaw ntawm cov tshuaj txhuam hniav, tus nqi ntawm cov tshuaj txhuam hniav siv, thiab lwm yam.

3. Txheej txheem kev pom zoo

Tsuas yog nyob rau hauv rooj plaub koj lub rooj tsavxwm PCB siv SMT cov khoom ntawm ob sab, yuav tsum tau txiav txim siab rov ua dua cov txheej txheem rau kev lees paub thib ob.koj yuav tuaj yeem taug qab lub sijhawm zoo tshaj plaws los nthuav tawm cov tshuaj nplaum rau hauv chav tsev kub ntawm no.Qhov no yog thaum koj lub rooj tsav xwm Circuit Court npaj tau los ua ke.Cov khoom siv tseem yuav tau npaj rau lub Hoobkas tom ntej.

4. Cov khoom siv sib dhos

Qhov no pib ua haujlwm nrog BOM (Bill of Materials) siv los ntawm CM rau kev txheeb xyuas cov ntaub ntawv.Qhov no pab txhawb kev txhim kho ntawm BOM cov khoom siv sib dhos.

5. Cov khoom ntim khoom nrog cov khoom

Siv cov barcode rub tawm ntawm cov khoom lag luam thiab muab tso rau hauv cov khoom siv sib dhos.Thaum cov khoom tau muab tso rau hauv cov khoom siv tag nrho, lawv raug coj mus rau qhov chaw xaiv thiab muab lub tshuab hu ua nto mount technology.

6. Kev npaj cov khoom siv rau kev tso kawm

Ib lub cuab yeej xaiv thiab qhov chaw yog ua haujlwm ntawm no los tuav txhua yam khoom sib dhos.Lub tshuab kuj siv lub cartridge uas tuaj nrog lub cim tshwj xeeb uas sib haum rau BOM cov khoom siv sib dhos.Lub tshuab yog tsim los qhia qhov chaw uas lub cartridge tuav.

Dab tsi yog txheej txheem rau SMT PCB los ua ke

Dab tsi yog SMT PCB sib dhos tuaj yeem muab tau?

SMT luam tawm Circuit Boards muaj ntau yam zoo.Qhov tseem ceeb tshaj plaws ntawm qhov zoo rau SMT yog qhov me me thiab lub teeb yuag.Tsis tas li ntawd, qee qhov zoo ntawm SMT suav nrog:

1. Ceev ntau lawm: Circuit Court boards tuaj yeem sib sau ua ke yam tsis muaj qhov drilling, uas txhais tau tias ntau lawm sai dua.

2. Siab dua Circuit Court ceev: Qhov tseeb, qhov no yog ib qho laj thawj tseem ceeb vim li cas SMT tau dhau los ua cov thev naus laus zis ntawm kev xaiv niaj hnub no.

3. Kev sib dhos automation: nws tuaj yeem paub txog automation thiab nws ntau yam zoo.

4. Tus nqi: Tus nqi ntawm cov khoom me me feem ntau yog qis dua li ntawm cov khoom hauv lub qhov.

5. Ceev ceev: Lawv tso cai rau cov khoom siv ntau ntxiv rau ntawm ob sab ntawm SMT luam tawm Circuit Board.

6. Tsim kom yooj yim: los ntawm qhov thiab SMT tivthaiv kev tsim khoom tuaj yeem ua ke los muab kev ua haujlwm ntau dua.

7. Kev ua tau zoo dua: SMT kev sib txuas yog txhim khu kev qha, yog li lub rooj tsavxwm tuaj yeem txhim kho kev ua haujlwm.

Dab tsi yog SMT PCB sib dhos tuaj yeem muab tau

Vim li cas thiaj xaiv peb SMT PCB kev pabcuam?

PCBFuture tau tsim nyob rau xyoo 2009, thiab peb muaj ntau tshaj li kaum xyoo hauv SMT PCB los ua ke.Peb tau cog lus los ua kom tau raws li qhov xav tau ntawm peb cov neeg siv khoom los ntawm kev lag luam sib txawv ntawm cov khoom zoo, kev xa khoom, kev ua tau zoo thiab kev daws teeb meem PCB.Kuj muab kev pabcuam tshwj xeeb.Peb kho PCB rau koj cov peev nyiaj thiab txuag koj lub sijhawm kom tau txais kev ua lag luam.

1. 24-teev online quote.

2. Kev pabcuam ceev 12-teev rau PCB qauv.

3. Tus nqi pheej yig thiab kev sib tw.

4. Kev xeem ua haujlwm raws li cov neeg siv khoom tshwj xeeb.

5. Peb pab neeg tshaj lij thiab txhim khu kev qha ua kom yooj yim rau koj los teeb tsa lossis daws teeb meem.Nov yog qhov peb xav kom txaus siab rau peb cov neeg siv khoom.Peb muab tag nrho cov kev pabcuam los ntawm kev tsim hluav taws xob mus rau cov cuab yeej ua tiav rau cov ntawv luam tawm Circuit Board.Peb yeej ib txwm zoo siab los muab kev pabcuam thawj zaug rau koj.

6. 10 xyoo dhau los hauv Electronics Cheebtsam kev yuav khoom.

7. Peb xa koj cov PCBs ncaj qha thiab sai sai tom qab ua tiav los ntawm lub Hoobkas.

8. Txhim khu kev qha SMT Hoobkas Nrog 8 SMT Kab, 100% Kev Ntsuas Kev Ua Haujlwm, Cov Qauv Tsim, Cov Nqi-zoo.

9. Peb tau nruab nrog cov cuab yeej siv siab tshaj plaws los xyuas kom meej tias peb muab cov khoom zoo.Peb kuj tseem muaj peev xwm muab koj cov kev pabcuam SMT sib dhos uas siv tag nrho cov hassle deb ntawm koj.

Vim li cas thiaj xaiv peb SMT PCB kev pabcuam

Cov txheej txheem SMT sib dhos yog hloov cov txheej txheem tsim khoom PCB thiab coj mus rau qib tom ntej.Qhov no yog tus nqi tsim nyog, ua haujlwm tau zoo thiab muaj kev ntseeg siab rau kev tsim PCBs.Qhov tsuas yog qhov xav tau yav tom ntej yog qhov tseeb ntawm kev txhim kho tag nrho SMT PCB thev naus laus zis vim nws tsis yog txheej txheem yooj yim.Qhov xwm zoo yog tias txawm niaj hnub no, koj tuaj yeem tau txais kev ntseeg siab PCB boards ntawm tus nqi pheej yig.Txawm li cas los xij, nws tsim nyog hu rau tus kws ua haujlwm txhim khu kev qha lossis cov chaw tsim khoom nrog cov khoom siv zoo tshaj plaws thiab kev paub dhau los kom ua tau raws li koj qhov kev xav tau ntawm pawg thawj coj saib.Txhawm rau pab koj nkag siab txog cov chaw tsim khoom zoo tshaj plaws, koj tuaj yeem xav txog kev siv cov cuab yeej siv niaj hnub no, cov khoom siv thawj zaug, tus nqi pheej yig, thiab cov tuam txhab tsim khoom xa tuaj raws sijhawm.

PCBFuture lub hom phiaj yog los muab kev lag luam nrog kev txhim khu kev qha PCB fabrication thiab kev sib dhos cov kev pabcuam los ntawm cov qauv mus rau kev tsim khoom hauv tus nqi zoo.Peb lub hom phiaj yog los pab txhua tus neeg siv los ua tus kws tshaj lij, ntau tus kws tshaj lij uas tuaj yeem ntseeg siab coj cov tswv yim tshiab, txiav-ntug engineering los ua haujlwm rau txhua yam haujlwm, teeb meem, thiab thev naus laus zis.
